Functions:
- Autonomous Navigation
- Automatic Return-to-Home
- Multi-Mode Navigation Control
- Integrated Information Display
- Monitoring & Alarm System
- Autonomous Obstacle Avoidance
- Dynamic Positioning
- Assisted Docking & Undocking
- Self-Diagnostics
Specification Value
Dimensions Length: 7.5 m, Beam: 2.7 m
Design Draft 0.4 m
Dry Weight Approx. 1.5 tons
Payload Capacity > 800 kg
Hull Type Rigid Inflatable Boat (RIB), Deep-V Monohull
Material Aluminum Alloy Hull + Hypalon Inflatable Tubes
Sea Condition Capability Normal Operation in Sea State 4
Fuel Tank Capacity 100 L
Cruising Speed 20 knots
Maximum Speed > 30 knots
Control Modes Onboard Manual Control, Remote Control, Autonomous Navigation
Communication Methods 4G, Broadband Mesh Network, Ku-band Satellite Communication, BeiDou/TianTong 3 Short Message, Handheld 2.4 GHz Remote Controller
Mission Payloads Electro-Optical Surveillance Gimbal, Long-Range Searchlight + High-Power Exploration Light
